Ram 2500 Diesel Leveling Kit, 2014 - Current

MetalCloak's Ram 2500 Leveling Kit, 2014+ raises the front of the truck and takes the rake out of the stance on your Ram. Unique to this leveling kit are 1/4" steel control arm correction brackets that flatten out the front control arm angles to maintain ride quality.

Features Include:
  • 3/16" Thick Welded Steel 2.5" Lift Spacers
  • 1/4" Welded and Trussed Control Arm Correction Brackets
  • Upper Extension Made of 5/8" Steel Hex Rod
  • Lower Extension Made of Strong 3/16" Steel Plate
  • All Required Hardware
  • Gold Zinc Finish
  • Easy Installation
  • Made in the USA
Raise the front of the factory stance of your 2014+ Ram truck and continue to [click for more...] enjoy the factory ride. MetalCloak provides lift for the front coils with 3/16" thick welded steel 2.5" lift spacers.

Control arm angles are flattened using our control arm correction bracket that corrects geometry ensuring a smooth and compliant ride; brackets are made of solid 1/4" steel, are trussed for extra strength and bolt directly into factory locations.

The thread on upper front extensions add length to the shock allowing the short shocks to mount where longer shocks would usually be fitted. Made of strong 5/8" hex rod the upper front extensions thread onto the upper portion of the factory shock and is finished in gold zinc.

The lower front shock mounts are made of strong 3/16” hot rolled steel and are CNC formed for a perfect fit. The shock brackets relocate the lower shock mount of the factory shocks up 3” to maximizes travel and performance of your truck.

All hardware is include and the components are gold zinc treated for a long lasting, good looking finish. Completely engineered/designed, fabricated, assembled and shipped from the USA.

[click for less...]


Availability
Currently Shipping in 5-10 Business Days
Price As Configured:
$799.00
Bread Checkout


VIDEOS

MetalCloak's Ram 2500 Suspension.

Who Is MetalCloak?

MetalCloak creates Game-Changing Products for the Off Road Enthusiast.

Ram 2500 Leveling Kit

MetalCloak's Ram 2500 Leveling Kit raises the front of the truck and removes the raked stance on your Ram and allows you to continue to enjoy a factory-like ride with a stouter-looking build on your Ram.

Why Gold Zinc?

It's time for The MetalCloak Minute... where we answer frequently asked questions in about a minute. Today's topic: Gold Zinc

Proudly Made in the USA

MetalCloak proudly manufactures products in America. Take a glimpse of Our incredible team that lives and breaths innovation and quality.

THE TECH

Ram 2500 Leveling Kit

Ram 2500 Lift Kit

MetalCloak's Ram 2500 Leveling Kit, 2014+ raises the front of the truck and takes the rake out of the stance on your Ram.

  • Front Control Arm Drop Brackets
  • 2.5" Front Coil Lift Spacers
  • Stock Shock Extensions

Front Control Arm Drop Bracket

Control arm angles are flattened using our control arm correction bracket that corrects geometry ensuring a smooth and compliant ride; brackets are made of solid 1/4" steel, are trussed for extra strength and bolt directly into factory locations.

Ram 2500 Front Control Arm Drop Brack on Truck

Front Coil Spacers

Ram 2500 Front Coil Spacer Kit on Truck

MetalCloak provides lift for the front coils with thick 3/16" hot rolled steel 2.5" lift spacers. The lift spacers install into factory locations and are gold zinc for corrosion resistance

Upper Front Shock Extension Kit

CNC machined, these stock shock extenders provide an easy way to adapt our basic lift kit without having to replace your front stock shocks.

Ram 2500 Stock Shock Extention Kit on Shock

Lower Front Shock Extension

Lower Front Gold Zinc Stock Shock Mount Installed in the Factory Shock Mount

The lower front shock mounts are made of strong 3/16” hot rolled steel and are CNC formed for a perfect fit. The shock brackets relocate the lower shock mount of the factory shocks up 3” to maximizes travel and performance of your truck. The shock mounts are finished in MetalCloak’s signature gold zinc to shield them against the elements and keep them looking great.

What's in the Kit?

  • Control Arm Drop Brackets
  • Front Coil Spacers
  • Front Upper Shock Extensions
  • Front Lower Shock Extensions
  • All Required Hardware
Whats in the Kit

TECHNICAL SPECIFICATIONS



Items Details
Compatibility 2014 - Current Ram 2500
Control Arm Drop Brackets 1/4" Hot Rolled Steel
Front Coil Spacers 3/16" Hot Rolled Steel
Front Upper Shock Extensions 5/8" Cold Rolled Steel Hex Rod
Front Lower Shock Extensions 3/16" Hot Rolled Steel
Steel Coating Gold Zinc


INSTALLATION



Installation Difficulty Easy
Body Modification None
Time to Install 2 - 3 Hours
Installation Instructions Click Here to see a full list of MetalCloak Installation Instructions.
