Frame-Built Bumper #230100, CJ
MetalCloak's Jeep CJ Frame-Built Bumper (Pre-Configured) - one of our most popular builds.
Features Include:- Frame Built Bumper Base
- 43” Lo-Crawler Caps
- Forward Angle Shackles
- All Hardware Required
- Easy Installation
- Made in the USA
The base is designed to mount all popular winch brands; the unique design ensures the winch is as low as possible for the best possible air flow through the Seven Slot grill.
The Lo-Pro Crawler Caps mounts directly to the MetalCloak frame built bumper base measuring 43” from end to end when installed. The crawler caps gives you a sleek low profile look, are made of strong laser cut 3/16” steel, have built in approach angles to help slide up and over obstacles, and is finished in MetalCloak’s signature black texture powder coat to help protect them against the elements.
The Forward Angle Shackles mount directly to the MetalCloak bumper base and are designed to hold 3/4" D-ring shackles. The shackle mounts provides a strong recovery point when out on the trail. The shackles are finished in a textured black powder coat to help protect them against the elements.
[click for less...]
VIDEOS
MetalCloak's Jeep Wrangler Bumpers.
Who Is MetalCloak?
MetalCloak creates Game-Changing Products for the Off Road Enthusiast.
Premium Black Powdercoat
Our signature Black Textured Powdercoat provides a micro-texture semi-gloss finish that is easily repairable after trail damage. Watch the video to learn more.
THE TECH
Front Bumper Base
The MetalCloak Front Bumper for the Jeep CJ Wranglers and provides a customized look.
- 3/16" Steel Plate
- 45° Approach Angle
- 30K PSI Yield Strength (Bend Point)
- 49K PSI Tensile Strength (Break Point)
- Seamless Construction (Zero Welds)
- Premium Black Texture Powder Coating
Specifications
The Frame-Built Bumper Base replaces the weak factory bumper with a 3/16" steel plate that is a sturdy platform for mounting a winch to.
Bolts directly on and works with all components.
43" Crawler Caps
The MetalCloak 43" Crawler Caps for the Jeep CJs and provides a customized look for MetalCloak frame-built front bumpers.
- 3/16" Hot Rolled Steel Plate
- 45° Approach Angle
- 50° Front Turning Clearance
- 45° Side Clearance Angle
- Seamless Construction (Zero Welds)
- Premium Black Texture Powder Coating
Specifications
The 43" Crawler Caps mounts directly to the MetalCloak bumper base and are made of 3/16" hot rolled steel plate and provides minimal obstructions and the best in approach angles.
Bolts directly on and works with all components.
Forward Angle Shackle Mounts
The MetalCloak Forward Angle Shackle Mount for CJ Jeep Frame-Built bumper provides a unique upper recovery mount that is trail-tested tough capable of handling anything you can throw at it.
- 3/16" Steel Plate
- Holds up to 3/4" Shackles/D-Rings
- Premium Black Texture Powder Coating
Specifications
The Forward Angle Shackle Mount directly to the MetalCloak bumper base and is designed to hold 3/4" D-ring shackles. The Forward Angle Shackle Mount are made of 3/16" Hot Rolled Steel and provide a strong recovery point when out on the trail. The hi-mount shackles are finished in textured black powder coat to help protect them against the elements.
Like all out components, they are Frame-Built and can be bolted directly to the frame with or without the Frame-Built Base.
What's in the Kit?
- Front Bumper
- 43" Lo-Crawler Caps
- Angle Shackle Mounts
- All Required Hardware
TECHNICAL SPECIFICATIONS
Items | Details |
---|---|
Compatibility | 1972 - 1986 CJ-5, CJ-7, CJ-8 |
Front Bumper Base | 3/16" Hot Rolled Steel Plate |
43" Lo-Crawler Caps | 3/16" Hot Rolled Steel Plate |
Angle Shackle Mounts | 3/16" Hot Rolled Steel |
Steel Coating | Black Powder Coat |
INSTALLATION
Installation Difficulty | Easy |
Body Modification | None |
Time to Install | 1 - 2 Hours |
Installation Instructions | Click Here to see a full list of MetalCloak Installation Instructions. |
